ASROCK B250M DASH - Page 4

2
English
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 Chassis Fan Connector (CHA_FAN1)
3 CPU Fan Connector (CPU_FAN1)
4 CPU Fan Connector (CPU_FAN2)
5 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
6 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)
7 ATX Power Connector (ATXPWR1)
8 USB 3.1 Gen1 Header (USB3_5_6)
9 SATA3 Connector (SATA3_0)
10 SATA3 Connector (SATA3_1)
11 Chassis Fan Connector (CHA_FAN2)
12 SATA3 Connector (SATA3_2)
13 SATA3 Connector (SATA3_3)
14 SATA3 Connector (SATA3_5)
15 SATA3 Connector (SATA3_4)
16 Clear CMOS Jumper (CLRMOS1)
17 Chassis Intrusion and Speaker Header (SPK_CI1)
18 System Panel Header (PANEL1)
19 USB 2.0 Header (USB5_6)
20 USB 2.0 Header (USB3_4)
21 TPM Header (TPMS1)
22 Print Port Header (LPT1)
23 COM Port Header (COM1)
24 COM Port Header (COM2)
25 Front Panel Audio Header (HD_AUDIO1)
