ASROCK B360 Pro4 User Manual

1
English
B360 Pro4
Motherboard Layout
Intel
B360
DDR4_A2 (64 bit, 288-pin module)
DDR4_A1 (64 bit, 288-pin module) DDR4_B2 (64 bit, 288-pin module)
DDR4_B1 (64 bit, 288-pin module)
ATX 12V1
USB 3. 1 Ge n1 T: USB3_1
B: USB3 _2
ATXPWR1
PCIE2
Top:
RJ-45
USB 2.0
T: USB_1
B: USB_2
PCIE4
HDLED RESET
PLED PWRBTN
PANEL1
1
USB_3_4
1
1
SPK_PLED1
COM1
1
1
HD_AUDIO1
B360 Pro4
PCIE1
RoHS
8
11
12
13
1
Ultra M.2
PCIe Gen3 x4
PS2
Keyb oar d
/Mou se
CMOS
Battery
PCIE3
24
10
6
USB3 _3 _4
1
23
1
TPMS1
M2_1
C 3C 2C 1C 4
7
USB 3.1
Top:
LINE IN
Cente r:
FRONT
Botto m:
MIC IN
SATA3_5
SATA3_4
PCI Express 3.0
SATA3 _2
SATA3 _3
SATA3 _0
SATA3 _1
USB_5
1
M2_3
M2_3_CT1
M2_2
C 7C 6C 5C 8
HDMI1
DVI1
VGA1
USB 3.1 Gen2
T:USB31_TA_1
B: USB31_TC_1
T B1
1
2
PCIE5
Antenna Port
T
T
T
T
T
T
T
T
AUDIO
CODEC
LAN
SUPER
I/O
AMD
CROSSFIRE
9
14
16
17
18
19
22
20
21
15
CLRMOS1
1
4
3
CHA_FAN2/WP
CHA_FAN3/WP
CHA_FAN1/WP
CPU_FAN1
5

ASROCK B360 Pro4 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2666 MHz
Processor socket	LGA 1151 (Socket H4)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	2
Number of SATA III connectors	6
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
Supported storage drive interfaces	M.2, SATA III
PCI Express x1 (Gen 3.x) slots	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Intel® I219-V
Ethernet interface type	Gigabit Ethernet
Audio chip	Realtek ALC892
Certification	FCC, CE, ErP/EuP
Component for	PC
Motherboard chipset	Intel® B360
PC health monitoring	CPU, FAN, Power supply, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64
DirectX version	12.0
Maximum resolution	4096 x 2160 pixels
Parallel processing technology support	4-Way CrossFireX, CrossFireX
BIOS type	UEFI AMI
ACPI version	6.0
BIOS memory size	128 Mbit
System Management BIOS (SMBIOS) version	2.7
Cables included	SATA
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	224 mm
Width	305 mm
