ASROCK B450M/ac R2.0 User Manual

B450M/ac R2.0
3
English
AMD Ryzen series CPUs (Picasso, Raven Ridge)
•
1 x PCI Express 3.0 x16 Slot (PCIE1: x8 mode)*
1 x PCI Express 2.0 x16 Slot (PCIE2: x4 mode)
AMD Athlon series CPUs
•
1 x PCI Express 3.0 x16 Slot (PCIE1: x4 mode)*
•
1 x PCI Express 2.0 x16 Slot (PCIE2: x4 mode)
* Supports NVMe SSD as boot disks
•
Supports AMD Quad CrossFireX
TM
and CrossFireX
TM
•
1 x Vertical M.2 Socket (Key E) with the bundled WiFi-
802.11ac module (on the rear I/O)
Graphics
•
Integrated AMD Radeon
TM
Vega Series Graphics in Ryzen
Series APU*
* Actual support may vary by CPU
•
DirectX 12, Pixel Shader 5.0
•
Shared memory default 2GB. Max Shared memory supports
up to 16GB.
* e Max shared memory 16GB requires 32GB system memory
installed.
•
Supports HDMI 1.4 with max. resolution up to 4K x 2K
(4096x2160) @ 24Hz / (3840x2160) @ 30Hz
•
Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant
HDMI monitor is required)
•
Supports HDCP 1.4 with HDMI 1.4 Port
•
Supports 4K Ultra HD (UHD) playback with HDMI 1.4 Port
Audio
•
7.1 CH HD Audio with Content Protection (Realtek
ALC892/897 Audio Codec)
•
Supports Surge Protection
LAN
•
PCIE x1 Gigabit LAN 10/100/1000 Mb/s
•
Realtek RTL8111H
•
Supports Wake-On-LAN
•
Supports Lightning/ESD Protection
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE

ASROCK B450M/ac R2.0 Specifications

General

Form Factor	Micro ATX
Chipset	AMD B450
Socket	AM4
Max Memory	64 GB
Memory Speed	DDR4 3200+(OC)
PCIe Slots	1 x PCIe 3.0 x16, 1 x PCIe 2.0 x1
Storage Interface	4 x SATA3
Audio	Realtek ALC887
Networking	Realtek Gigabit LAN
Bluetooth	Bluetooth 4.2
Video Outputs	1 x HDMI
Memory Slots	4 x DIMM
