ASROCK B550 PG Riptide - Page 14

English
8
No. Description
1 8 pin 12V Power Connector (ATX12V1)
2 4 pin 12V Power Connector (ATX12V2)
3 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
4 CPU Fan Connector (CPU_FAN1)
5 Chassis / Waterpump Fan Connector (CHA_FAN4/WP)
6 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)
7 Chassis / Waterpump Fan Connector (CHA_FAN5/WP)
8 Addressable LED Header (ADDR_LED2)
9 RGB LED Header (RGB_LED2)
10 ATX Power Connector (ATXPWR1)
11 USB 3.2 Gen1 Header (USB3_9_10)
12 Front Panel Type C USB 3.2 Gen2 Header (USB31_TC_2)
13 SPI TPM Header (SPI_TPM_J1)
14 USB 3.2 Gen1 Header (USB3_7_8)
15 SATA3 Connector (SATA3_2) (Upper), SATA3 Connector (SATA3_1) (Lower)
16 SATA3 Connector (SATA3_4) (Upper), SATA3 Connector (SATA3_3) (Lower)
17 SATA3 Connector (SATA3_6) (Upper), SATA3 Connector (SATA3_5) (Lower)
18 Chassis / Waterpump Fan Connector (CHA_FAN3/WP)
19 System Panel Header (PANEL1)
20 Power LED and Speaker Header (SPK_PLED1)
21 Post Status Checker (PSC)
22 underbolt AIC Header (TB1)
23 Clear CMOS Jumper (CLRCMOS1)
24 USB 2.0 Header (USB_7_8)
25 USB 2.0 Header (USB_5_6)
26 USB 2.0 Header (USB_3_4)
27 Chassis/Water Pump Fan Connector (CHA_FAN2/WP)
28 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
29 Addressable LED Header (ADDR_LED1)
30 RGB LED Header (RGB_LED1)
31 Front Panel Audio Header (HD_AUDIO1)
32 CPU / Waterpump Fan Connector (CPU_FAN2/WP)
