English
5
B550M PG Riptide
•
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
•
HD Audio Jacks: Line in / Front Speaker / Microphone
Storage
•
4 x SATA3 6.0 Gb/s Connectors
•
1 x Hyper M.2 Socket (M2_1, Key M), supports type
2260/2280 PCIe Gen4x4 (64 Gb/s) mode (with Vermeer,
Matisse) or Gen3x4 (32 Gb/s) mode (with Cezanne, Renoir
and Picasso)*
•
1 x M.2 Socket (M2_2, Key M), supports type 2260/2280
SATA3 6.0 Gb/s & PCIe Gen3x2 (16 Gb/s) modes*
* Supports NVMe SSD as boot disks
* Supports ASRock U.2 Kit
RAID
•
Supports RAID 0, RAID 1 and RAID 10 for SATA storage
devices
•
Supports RAID 0 and RAID 1 for M.2 NVMe storage de-
vices
Connector
•
1 x SPI TPM Header
•
1 x Power LED and Speaker Header
•
2 x RGB LED Headers
* Support in total up to 12V/3A, 36W LED Strip
•
2 x Addressable LED Headers
* Support in total up to 5V/3A, 15W LED Strip
•
1 x CPU Fan Connector (4-pin)
* e CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
•
1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan
Speed Control)
* e CPU/Water Pump Fan supports the water cooler fan of
maximum 2A (24W) fan power.
•
4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan
Speed Control)
* e Chassis/Water Pump Fan supports the water cooler fan of
maximum 2A (24W) fan power.
* CPU_FAN2/WP, CHA_FAN1/WP, CHA_FAN2/WP, CHA_
FAN3/WP and CHA_FAN4/WP can auto detect if 3-pin or 4-pin
fan is in use.
