8
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 ATX 12V Power Connector (ATX12V2)
3 CPU Fan Connector (CPU_FAN1)
4 CPU/Water Pump Fan Connector (CPU_FAN2/WP)
5 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1)
6 Post Status Checker (PSC)
7 2 x 288-pin DDR5 DIMM Slots (DDR5_A2, DDR5_B2)
8 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
9 Addressable LED Header (ADDR_LED2)
10 ATX Power Connector (ATXPWR1)
11 Front Panel Type C USB 3.2 Gen2 Header (USB32_TC2)
12 USB 3.2 Gen1 Header (USB32_8_9)
13 Chassis/Water Pump Fan Connector (CHA_FAN2/WP)
14 SPI TPM Header (SPI_TPM_J1)
15 SATA3 Connector (SATA3_1)
16 SATA3 Connector (SATA3_2)
17 System Panel Header (PANEL1)
18 Power LED and Speaker Header (SPK_PLED1)
19 SATA3 Connector (SATA3_4)
20 SATA3 Connector (SATA3_3)
21 USB 2.0 Header (USB_7_8)
22 USB 2.0 Header (USB_5_6)
23 Clear CMOS Jumper (CLRCMOS1)
24 Chassis/Water Pump Fan Connector (CHA_FAN4/WP)
25 Addressable LED Header (ADDR_LED3)
26 Addressable LED Header (ADDR_LED1)
27 RGB LED Header (RGB_LED1
)
28 Front Panel Audio Header (HD_AUDIO1)
29 CPU/Water Pump Fan Connector (CPU_FAN3/WP)
