ASROCK B650 PG LIGHTNING - Page 45

41
B650 PG Lightning WiFi
B650 PG Lightning
Power LED and Speaker Header
(7-pin SPK_PLED1) (see p.6, 7, No. 18)
Please connect the chassis power LED and the chassis speaker to this header.
1
+5V
DUMMY
PLED+
PLED+
PLED-
DUMMY
SPEAKER
SPK_PLED1
