4
•
1 x M.2 Socket (M2_3, Key M), supports type 2260/2280
SATA3 6.0 Gb/s & PCIe Gen3x2 (16 Gb/s) modes*
•
4 x SATA3 6.0 Gb/s Connectors**
* Supports NVMe SSD as boot disks
** M2_3 and SATA3_3_4 share lanes. If either one of them is in
use, the other one will be disabled.
RAID
•
Supports RAID 0, RAID 1 and RAID 10 for SATA storage
devices
•
Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe stor-
age devices*
* Requires additional M.2 NVMe expansion cards to support
RAID 10
** M2_3 and SATA3_3_4 share lanes. If either one of them is in
use, the other one will be disabled.
Connector
•
1 x SPI TPM Header
•
1 x Power LED and Speaker Header
•
1 x RGB LED Header*
•
3 x Addressable LED Headers**
•
1 x CPU Fan Connector (4-pin)***
•
1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan
Speed Control)****
•
3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan
Speed Control)*****
•
1 x 24 pin ATX Power Connector
•
1 x 8 pin 12V Power Connector
•
1 x 4 pin 12V Power Connector
•
1 x Front Panel Audio Connector
•
1 x underbolt AIC Connector (5-pin) (Supports ASRock
underbolt 4 AIC Card)
•
2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
•
2 x USB 3.2 Gen1 Headers (Support 4 USB 3.2 Gen1 ports)
•
1 x Front Panel Type C USB 3.2 Gen1 Header
* Supports in total up to 12V/3A, 36W LED Strip
** Support in total up to 5V/3A, 15W LED Strip
*** CPU_FAN1 supports the fan power up to 1A (12W).
**** CPU_FAN2/WP supports the fan power up to 2A (24W).
***** CHA_FAN1~3/WP support the fan power up to 2A (24W).
***** CPU_FAN2/WP and CHA_FAN1~3/WP can auto detect
if 3-pin or 4-pin fan is in use.
