140
Bahasa Indonesia
Spesikasi
Platform
•
Bentuk dan Ukuran Mini-ITX
•
Desain Kapasitor Solid
CPU
•
Mendukung Prosesor Intel® Core
TM
Gen ke-12 (LGA1700)
•
Desain Digi Power
•
Desain 6 Fase Daya
•
Mendukung Teknologi Intel® Hybrid
•
Mendukung Teknologi Intel® Turbo Boost Max 3.0
Chipset
•
Intel® B660
Memori
•
Teknologi Memori DDR4 Dua Saluran
•
2 x Slot DIMM DDR4
•
Mendukung memori DDR4 non-ECC, tanpa buer hingga
5000+(OC)*
* Mendukung DDR4 3200 secara native.
* Lihat Daar Dukungan Memori pada situs web ASRock untuk
informasi selengkapnya. (http://www.asrock.com/)
•
Mendukung modul memori ECC UDIMM (berjalan dalam mode
non-ECC)
•
Kapasitas maksimum memori sistem: 64GB
•
Mendukung Intel® Extreme Memory Prole (XMP) 2.0
Slot Ekspansi
•
1 slot PCIe Gen4x16*
* Mendukung SSD NVMe sebagai disk boot
•
1 x Soket M.2 Vertikal (Tombol E), mendukung modul jenis 2230
WiFi/WiFi BT PCIe dan Intel® CNVi (WiFi/BT terintegrasi)
Gras
* Intel® UHD Graphics Built-in Visuals dan output VGA hanya
didukung dengan prosesor yang terintegrasi GPU.
•
Arsitektur Gras Intel® X
e
(Gen 12)
•
Output gras ganda: Mendukung port HDMI dan DisplayPort 1.4
melalui pengontrol layar mandiri
•
Mendukung HDMI 2.1 TMDS Kompatibel dengan maks. resolusi
hingga 4K x 2K (4096x2160) @ 60Hz

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK B660M-ITX/ac and is the answer not in the manual?

ASROCK B660M-ITX/ac Specifications

General IconGeneral
Processor socketLGA 1700
Processor manufacturerIntel
Compatible processor seriesIntel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Maximum number of SMP processors1
Audio chipRealtek ALC897
Component forPC
Motherboard chipsetIntel B660
PC health monitoringCPU, FAN, Temperature, Voltage
Audio output channels7.1 channels
Motherboard form factormini ITX
Windows operating systems supportedWindows 10 x64, Windows 11 x64
ECCYes
Memory slots typeDIMM
Number of memory slots2
Supported memory typesDDR4-SDRAM
Maximum internal memory64 GB
Supported memory clock speeds5000 MHz
RAID levels0, 1, 5, 10
Supported storage drive typesHDD & SSD
Supported storage drive interfacesSATA III
Cables includedSATA
DisplayPort version1.4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity0
Number of SATA III connectors4
Maximum resolution7680 x 4320 pixels
Parallel processing technology supportNot supported
LAN controllerIntel® I219-V
Top Wi-Fi standardWi-Fi 5 (802.11ac)
Ethernet interface typeGigabit Ethernet
Harmonized System (HS) code84733020
Weight and Dimensions IconWeight and Dimensions
Width170 mm
