Page #6 background imageLoading...
Page #6 background image
6
ASRock B75 Pro3 Motherboard
English
1.2 Specifications
Platform - ATX Form Factor: 12.0-in x 7.6-in, 30.5 cm x 19.3 cm
- All Solid Capacitor design
CPU - Supports 3
rd
and 2
nd
Generation Intel
®
Core
TM
i7 / i5 / i3 in
LGA1155 Package
- 4 + 1 Power Phase Design
- Supports Intel
®
Turbo Boost 2.0 Technology
- Supports Intel
®
K-Series unlocked CPU (see CAUTION 1)
- Supports Hyper-Threading Technology (see CAUTION 2)
- Supports Intel
®
Rapid Start Technology and Smart Connect
Technology with Intel
®
Ivy Bridge CPU
Chipset - Intel
®
B75
- Supports Intel
®
Small Business Advantage (see CAUTION 3)
Memory - Dual Channel DDR3 Memory Technology (see CAUTION 4)
- 4 x DDR3 DIMM slots
- Supports DDR3 1600/1333/1066 non-ECC, un-buffered
memory (DDR3 1600 with Intel
®
Ivy Bridge CPU, DDR3
1333 with Intel
®
Sandy Bridge CPU)
- Max. capacity of system memory: 32GB (see CAUTION 5)
- Supports Intel
®
Extreme Memory Prole (XMP)1.3/1.2
Expansion Slot - 1 x PCI Express 3.0 x16 slot (PCIE1: x16 mode)
(see CAUTION 6)
* PCIE 3.0 is only supported with Intel
®
Ivy Bridge CPU. With
Intel
®
Sandy Bridge CPU, it only supports PCIE 2.0.
- 1 x PCI Express 2.0 x16 slot (PCIE2: x4 mode)
- 1 x PCI Express 2.0 x 1 slot
- 2 x PCI slots
- Supports AMD Quad CrossFireX
TM
and CrossFireX
TM
Graphics * Intel
®
HD Graphics Built-in Visuals and the VGA outputs can
be supported only with processors which are GPU
integrated.
- Supports Intel
®
HD Graphics Built-in Visuals: Intel
®
Quick
Sync Video 2.0, Intel
®
InTru
TM
3D, Intel
®
Clear Video HD
Technology, Intel
®
Insider
TM
, Intel
®
HD Graphics 2500/4000
- Pixel Shader 5.0, DirectX 11 with Intel
®
Ivy Bridge CPU.
Pixel Shader 4.1, DirectX 10.1 with Intel
®
Sandy Bridge CPU
- Max. shared memory 1760MB (see CAUTION 7)
- Three VGA Output options: D-Sub, DVI-D and HDMI
(see CAUTION 8)
- Supports HDMI 1.4a Technology with max. resolution up to

Other manuals for ASROCK B75 Pro3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK B75 Pro3 and is the answer not in the manual?

ASROCK B75 Pro3 Specifications

General IconGeneral
ECCNo
Non-ECCYes
Memory voltage1.5 V
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots4
Supported memory typesDDR3-SDRAM
Maximum internal memory32 GB
Supported memory clock speeds1066, 1333, 1600 MHz
Supported memory module capacities16GB, 1GB, 2GB, 4GB, 8GB
System bus rate5 GT/s
Processor socketLGA 1155 (Socket H2)
Processor manufacturerIntel
Compatible processor seriesIntel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors1
USB 2.0 connectors2
Number of SATA II connectors5
Number of SATA III connectors3
Number of Parallel ATA connectors0
HDMI version1.4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chipRealtek ALC892
Cooling typePassive
CertificationFCC, CE, WHQL, ErP/EuP Ready
Component forPC
Motherboard chipsetIntel B75
PC health monitoringCPU, FAN, Temperature
Audio output channels7.1 channels
Motherboard form factorATX
Compatible operating systemsWindows 7, Vista, XP 32/64-bit
Supported storage drive interfacesSATA II, SATA III
Cables includedSATA
Graphics cardHD Graphics
OpenGL version3.2
DirectX version11
Maximum resolution2048 x 1536 pixels
Maximum graphics card memory1760 MB
Parallel processing technology support2-Way CrossFireX, Quad-GPU CrossFireX
PCI Express slots version2.0, 3.0
PCI Express configurations1x4, 1x16
Controller 2nd interface typeASMedia ASM1061
LAN controllerRealtek RTL8111E
Wi-Fi standardsNot supported
Networking featuresGigabit LAN
Ethernet interface typeGigabit Ethernet
BIOS typeEFI AMI
ACPI version1.1
BIOS memory size64 Mbit
Weight and Dimensions IconWeight and Dimensions
Depth193 mm
Width305 mm
