ASROCK B760M PC LIGHTNING - Page 11

7
B760M PG Lightning
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
3 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)
4 CPU Fan Connector (CPU_FAN1)
5 CPU/Water Pump Fan Connector (CPU_FAN2/WP)
6 ATX Power Connector (ATXPWR1)
7 USB 3.2 Gen1 Header (USB32_4_5)
8 SATA3 Connector (SATA3_3)(Lower)
9 SATA3 Connector (SATA3_2)(Upper)
10 System Panel Header (PANEL1)
11 SATA3 Connector (SATA3_0)
12 SATA3 Connector (SATA3_1)
13 SPI TPM Header (SPI_TPM_J1)
14 Post Status Checker (PSC)
15 Chassis/Water Pump Fan Connector (CHA_FAN4/WP)
16 USB 2.0 Header (USB_5_6)
17 USB 2.0 Header (USB_3_4)
18 5-pin underbolt AIC Connector (TB1)
19 Chassis Intrusion and Speaker Header (SPK_CI1)
20 Chassis/Water Pump Fan Connector (CHA_FAN2/WP)
21 Chassis/Water Pump Fan Connector (CHA_FAN3/WP)
22 Clear CMOS Jumper (CLRMOS1)
23 Front Panel Audio Header (HD_AUDIO1)
24 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
