ASROCK B760M PG RIPTIDE - Page 45

English
41
B760M PG Riptide
Step 3
Before installing a M.2 SSD
module, please loosen the screws to
remove the M.2 heatsink.
*Please remove the protective lms
on the bottom side of the M.2
heatsink before you install a M.2
SSD module.
Step 4
Align and gently insert the M.2 SSD
module into the M.2 slot. Please
be aware that the M.2 SSD module
only ts in one orientation.
A
A
20
o
1
1
2
