ASROCK B85 Pro4 User Manual

2
English
1.2 Specications
Platform
•
ATX Form Factor
•
All Solid Capacitor design
CPU
•
Supports 4th Generation Intel® CoreTM i7 / i5 / i3 / Xeon® /
Pentium® / Celeron® in LGA1150 Package
•
Digi Power Design
•
4 Power Phase Design
•
Supports Intel
®
Turbo Boost 2.0 Technology
Chipset
•
Intel® B85
•
Supports Intel® Small Business Advantage 2.0
Memory
•
Dual Channel DDR3 memory technology
•
4 x DDR3 DIMM slots
•
Supports DDR3 1600/1333/1066 non-ECC, un-buered
memory
•
Max. capacity of system memory: 32GB
•
Supports Intel® Extreme Memory Prole (XMP) 1.3 / 1.2
Expansion
Slot
•
1 x PCI Express 3.0 x16 slot (PCIE2: x16 mode)
•
1 x PCI Express 2.0 x16 slot (PCIE4: x4 mode)
•
2 x PCI Express 2.0 x1 slots
•
2 x PCI slots
•
Supports AMD Quad CrossFireX
TM
and CrossFireX
TM

ASROCK B85 Pro4 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1666 MHz
Supported memory module capacities	2GB, 4GB, 8GB
Processor socket	LGA 1150 (Socket H3)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
USB 2.0 connectors	2
Number of SATA connectors	6
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Certification	FCC, CE, WHQL
Component for	PC
Motherboard chipset	Intel® B85
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
Supported storage drive interfaces	SATA II, SATA III
Maximum resolution	1920 x 1200 pixels
Parallel processing technology support	Quad-GPU CrossFireX
PCI Express slots version	2.0, 3.0
Cables included	SATA
LAN controller	Intel® I217-V
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
BIOS type	UEFI AMI
ACPI version	1.1
BIOS memory size	64 Mbit

Weight and Dimensions

Width	- mm
