4 5
English
•
1 x 8 pin 12V Power Connector (Hi-Density Power
Connector)
•
1 x 4 pin 12V Power Connector (Hi-Density Power
Connector)
•
1 x Vertical Type A USB 2.0
•
1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports
ESD Protection)
•
1 x USB 3.2 Gen1 Headers (Support 2 USB 3.2 Gen1 ports)
(Supports ESD Protection)
•
2 x USB3.2 Gen2 ports (2 Type-C headers)
•
2 x Front Panel Type C USB 3.2 Gen2 Headers (Supports ESD
Protection)
•
2 x SGPIO Headers
•
1 x Auxiliary Panel Header
•
1 x Intelligent Platform Management Bus Header
•
1 x Backplane PCI Express Hot-Plug Connector Header
•
1 x SMBus Header
•
1 x PMbus Header
•
1 x CPU HP-SMBus Connector
•
1 x ermal Sensor Header
•
1 x Virtual RAID On CPU Header
•
1 x BMC Heartbeat LED
•
1 x StandbyPower LED
•
5 x FanFail LED
•
1 x Non Maskable Interrupt Button Header
•
1 x Buzzer
•
1 x Dr. Debug with LED
BIOS
Feature
•
AMI UEFI Legal BIOS
•
ACPI 5.0 Compliant wake up events
•
SMBIOS 2.3 Support
Hardware
Monitor
•
Temperature Sensing: CPU, PCH, MB, Card Side
•
Fan Tachometer: CPU, Rear, Front Fan Tachometer
•
Quiet Fan (Auto adjust chassis fan speed by CPU
temperature): CPU Fan
•
Fan Multi-Speed Control: CPU, Rear, Front Fan
•
Voltage Monitoring: CPU1_PVCCIN, PVDDQ_
ABCD,PVDDQ_EFGH, 1.05V_PCH,1.8V_PCH,
+BAT,PVNN_PCH, 3.3V,5V,12V,3.3VSB, 5VSB
