C621A WS
6 7
English
No. Description
1 Backplane PCI Express Hot-Plug Connector (CPU1_HSBP1)
2 PSU SMBus Header (PSU_SMB1)
3 System Fan Connector (FAN1)
4 ATX Power Connector (ATXPWR1)
5 ATX 12V Power Connector (ATX12V1)
6 USB 3.2 Gen1 Header (USB3_5_6)
7 ATX 12V Power Connector (ATX12V2)
8 System Fan Connector (FAN2)
9 LGA 4189 CPU Socket (CPU1)
10 CPU VSENSE Header (CPU_VSENSE)
11 PWM Conguration Header (PWM_CFG1)
12 SATA DOM Power Connector (SATAPWR2)
13 System Fan Connector (FAN3)
14 System Fan Connector (FAN4)
15 SATA DOM Power Connector (SATAPWR1)
16 SATA3 DOM Connector (SATA_5)
17 2 x 288-pin DDR4 DIMM Slots (DDR4_E1, DDR4_G1)*
18 SATA3 DOM Connector (SATA_4)
19 System Fan Connector (FAN5)
20 2 x 288-pin DDR4 DIMM Slots (DDR4_F1, DDR4_H1)*
21 M.2 Socket (M2_1) (Type 2242/2280/22110)
22 Mini-SAS HD Connector (SATA_0_3)
23 Front Panel Type C USB 3.2 Gen2 Header (USB31_TC_1)**
24 Front Panel Type C USB 3.2 Gen2 Header (USB31_TC_2)**
25 SATA3 Connectors (SSATA_3)(Upper), (SSATA3_2)(Lower)**
26 Speaker Header (SPEAKER1)
27 USB 2.0 Header (USB_2_3)
28 Virtual RAID On CPUHeader (RAID_1)
29 System Panel Header (PANEL1)
30 Auxiliary Panel Header (AUX_PANEL1)
31 M.2 Socket (M2_2) (Type 2242/2280/22110)
32 TPM-SPI Header (TPM_BIOS_PH1)
33 Security Override Jumper (SEC_OR1)
