ASROCK Fatal1ty 970 Performance/3.1 Series Manual

2
English
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 Power Fan Connector (PWR_FAN1)
3 CPU Fan Connector (CPU_FAN2)
4 CPU Fan Connector (CPU_FAN1)
5 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
6 2 x 240-pin DDR3 DIMM Slots (DDR3_A2, DDR3_B2)
7 Chassis Fan Connector (CHA_FAN1)
8 ATX Power Connector (ATXPWR1)
9 USB 3.0 Header (USB3_5_6)
10 SATA3 Connector (SATA3_0)
11 SATA3 Connector (SATA3_2)
12 SATA3 Connector (SATA3_4)
13 SATA3 Connector (SATA3_5)
14 SATA3 Connector (SATA3_3)
15 SATA3 Connector (SATA3_1)
16 Chassis Fan Connector (CHA_FAN2)
17 Chassis Fan Connector (CHA_FAN3)
18 Clear CMOS Jumper (CLRCMOS1)
19 Chassis Speaker Header (SPEAKER1)
20 System Panel Header (PANEL1)
21 Power LED Header (PLED1)
22 TPM Header (TPMS1)
23 USB 2.0 Header (USB_6_7)
24 USB 2.0 Header (USB_8_9)
25 USB 2.0 Header (USB_4_5)
26 PCIe Power Connector (SLI/XFIRE_PWR1)
27 COM Port Header (COM1)
28 SPDIF Out Connector (SPDIF_OUT1)
29 PCIe Power Connector (PCIE_PWR1)
30 Front Panel Audio Header (HD_AUDIO1)

ASROCK Fatal1ty 970 Performance/3.1 Series Specifications

General

CPU Socket	AM3+
Chipset	AMD 970 + SB950
Memory Slots	4 x DDR3 DIMM
Max Memory	64GB
Storage Interface	6 x SATA3 6.0 Gb/s
Form Factor	ATX
Expansion Slots	2 x PCIe 2.0 x16, 2 x PCIe 2.0 x1
USB Ports	8 x USB 2.0
Audio	Realtek ALC1150
LAN	Gigabit LAN 10/100/1000 Mb/s (Realtek RTL8111GR)
