ASROCK Fatal1ty B360 Gaming K4 Series User Manual

English
2
No. Description
1 RGB LED Header (RGB_LED2)
2 ATX 12V Power Connector (ATX12V1)
3 CPU Fan Connector (CPU_FAN1)
4 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
5 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)
6 ATX Power Connector (ATXPWR1)
7 USB 3.1 Gen1 Header (USB3_3_4)
8 SATA3 Connectors (SATA_4_5)
9 SATA3 Connectors (SATA_2_3)
10 SATA3 Connectors (SATA_0_1)
11 System Panel Header (PANEL1)
12 Power LED and Speaker Header (SPK_PLED1)
13 Chassis/Water Pump Fan Connector (CHA_FAN3/WP)
14 Chassis/Water Pump Fan Connector (CHA_FAN2/WP)
15 USB 2.0 Header (USB_3_4)
16 USB 2.0 Header (USB_5_6)
17 Addressable LED Header (ADDR_LED1)
18 RGB LED Header (RGB_LED1)
19 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
20 COM Port Header (COM1)
21 TPM Header (TPMS1)
22 Chassis Intrusion Header (CI1)
23 Front Panel Audio Header (HD_AUDIO1)
24 underbolt AIC Connector (TB1)
25 Clear CMOS Jumper (CLRMOS1)
26 CPU/Water Pump Fan Connector (CPU_FAN2/WP)

ASROCK Fatal1ty B360 Gaming K4 Series Specifications

General

Chipset	Intel B360
CPU Socket	LGA 1151
Maximum Memory	64 GB
SATA 6Gb/s Ports	6
M.2 Slots	2
Form Factor	ATX
RAID Support	RAID 0, 1, 5, 10
Memory Slots	4
Memory Speed	DDR4 2666/2400/2133 MHz
PCIe 3.0 x16 Slots	2
PCIe 3.0 x1 Slots	3
USB 3.1 Gen1 Ports	6
USB 3.1 Gen2 Ports	2
USB 2.0 Ports	6
Audio	Realtek ALC892
LAN	Intel I219V
