ASROCK Fatal1ty B85 Killer Series User Manual

4
English
LAN
•
PCIE x1 Gigabit LAN 10/100/1000 Mb/s
•
Qualcomm® Atheros® Killer
TM
E2200 Series
•
Supports Wake-On-LAN
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE
Rear Panel
I/O
•
1 x PS/2 Mouse/Keyboard Port
•
1 x D-Sub Port
•
1 x DVI-D Port
•
1 x HDMI Port
•
1 x Optical SPDIF Out Port
•
3 x USB 2.0 Ports
•
1 x Fatal1ty Mouse Port (USB 2.0)
•
2 x USB 3.0 Ports
•
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
•
HD Audio Jack: Rear Speaker / Central / Bass / Line in / Front
Speaker / Microphone
Storage
•
4 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and
Hot Plug
•
2 x SATA2 3.0 Gb/s Connectors, support NCQ, AHCI and
Hot Plug
Connector
•
1 x Power LED Header
•
2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)
•
3 x Chassis Fan Connectors (1 x 4-pin, 2 x 3-pin)
•
1 x Power Fan Connector (3-pin)
•
1 x 24 pin ATX Power Connector
•
1 x 8 pin 12V Power Connector (Hi-Density Power
Connector)
•
1 x Front Panel Audio Connector
•
2 x USB 2.0 Headers (Support 4 USB 2.0 ports)
•
1 x USB 3.0 Header (Supports 2 USB 3.0 ports)
BIOS
Feature
•
64Mb AMI UEFI Legal BIOS with multilingual GUI support
•
ACPI 1.1 Compliant wake up events
•
SMBIOS 2.3.1 support
•
CPU, DRAM, PCH 1.05V, PCH 1.5V Voltage multi-adjust-
ment

ASROCK Fatal1ty B85 Killer Series Specifications

General

Chipset	Intel B85
Socket	LGA 1150
Max Memory	32GB
Audio	Realtek ALC1150
LAN	Qualcomm Atheros Killer E2200
Form Factor	ATX
RAID Support	RAID 0, 1, 5, 10
Multi-GPU Support	AMD Quad CrossFireX
Memory Standard	DDR3
Expansion Slots	2 x PCI Express 2.0 x1, 2 x PCI
Storage	4 x SATA 6Gb/s, 2 x SATA 3Gb/s
USB Ports	8 x USB 2.0 (4 rear, 4 via header)
Memory Slots	4 x DIMM
