ASROCK Fatal1ty B85 Killer Series User Manual

63
English
Fatal1ty B85 Killer Series
MRC Fast Boot
Enable Memory Fast Boot to skip DRAM memory training for booting faster.
DIMM Exit Mode
Select Slow Exit to reduce power consumption, or Fast Exit for better performance.
FIVR Conguration
FIVR Switch Frequency Signature
Select whether to boost or lower the FIVR Switch Frequency.
FIVR Switch Frequency Oset
Congure the percentage of frequency boost or deduction.
Vcore Override Voltage
Add voltage to the Vcore when the system is under heavy load.
Vcore Voltage Additional Oset
Congure the dynamic Vcore voltage added to the Vcore.
CPU Cache Override Voltage
Add voltage to the CPU Cache when the system is under heavy load.
CPU Cache Voltage Oset
Congure the voltage for the CPU Cache. Setting the voltage higher may increase
system stability when overclocking.
System Agent Voltage Oset
Congure the voltage for the System Agent. Setting the voltage higher may increase
system stability when overclocking.
CPU Analog IO Voltage Oset
CPU I/O Analog Voltage.
CPU Digital IO Voltage Oset
CPU I/O Digital Voltage.
CPU Integrated VR Faults
Disable FIVR Faults to raise the threshold to trigger CPU over current protection
and over voltage protection for better overclocking capabilities.

ASROCK Fatal1ty B85 Killer Series Specifications

General

Chipset	Intel B85
Socket	LGA 1150
Max Memory	32GB
Audio	Realtek ALC1150
LAN	Qualcomm Atheros Killer E2200
Form Factor	ATX
RAID Support	RAID 0, 1, 5, 10
Multi-GPU Support	AMD Quad CrossFireX
Memory Standard	DDR3
Expansion Slots	2 x PCI Express 2.0 x1, 2 x PCI
Storage	4 x SATA 6Gb/s, 2 x SATA 3Gb/s
USB Ports	8 x USB 2.0 (4 rear, 4 via header)
Memory Slots	4 x DIMM
