ASROCK Fatal1ty B85 Killer User Manual

1
English
Fatal1ty B85 Killer Series
Motherboard Layout
Intel
B85
DDR3_A2 (64 bit, 240-pin module)
DDR3_A1 (64 bit, 240-pin module)
DDR3_B2 (64 bit, 240-pin module)
DDR3_B1 (64 bit, 240-pin module)
ATX 12V1
CMOS
Battery
Supe r
I/O
USB 2.0
T: USB0
B: USB1
PS2
Mouse /
Keybo ard
ATXPWR1
1
USB3_ 2_ 3
Killer
E2200
PCIE2
Top:
RJ-45
USB 2.0
T: USB2
B: USB3
Top:
Central /B as s
Center:
REAR SPK
Top:
LINE IN
Center:
FRONT
Bottom:
Optical
SPDIF
Bottom:
MIC IN
PCIE4
CLRCMOS1
1
PLED1
1
1
SPEAKER1
HDLED RESET
PLED PWRBTN
PANEL1
1
USB6_7
1
USB4_5
1
1
HD_AUDIO1
B85 Killer
SATA2_0
PCIE1
CHA_FAN1
CHA_FAN2
CHA_FAN3
PCI1
PCI2
RoHS
7
8
9
10
14
11
12
13
16
1819
20
21
17
15
2
CPU_FAN1
CPU_FAN2
3
4
6
5
1
24
22
HDMI1
FATALTY1
Purity
Sound
TM
VGA1
DVI1
PWR_FAN1
SATA2_1
SATA3_2
SATA3_3
SATA3_0
SATA3_1
PCI3
PCIE3
USB 3.0
T: USB0
B: USB1
64Mb
BIOS
23

ASROCK Fatal1ty B85 Killer Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
Processor socket	LGA 1150 (Socket H3)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Intel® Core i3/i5/i7/i9 series	i3-4xxx, i5-4xxx, i7-4xxx
USB 2.0 connectors	2
Number of SATA connectors	6
Number of Parallel ATA connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
Supported storage drive interfaces	SATA II, SATA III
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Atheros Killer E2200
Ethernet interface type	Gigabit Ethernet
Audio chip	Realtek ALC1150
Certification	FCC, CE, WHQL, ErP/EuP
Component for	PC
Motherboard chipset	Intel® B85
PC health monitoring	CPU, FAN, Power supply, Temperature
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
DirectX version	11.1
Maximum resolution	4096 x 2304 pixels
Maximum graphics card memory	1792 MB
Parallel processing technology support	Quad-GPU CrossFireX
BIOS type	UEFI AMI
ACPI version	1.1
BIOS memory size	64 Mbit
Cables included	SATA
Bundled software	Drivers, Utilities, AntiVirus Software (Trial version), Google Chrome Browser and Toolbar, Start8 (30 days trial), XSplit, Killer Network Manager

Weight and Dimensions

Width	- mm
