ASROCK Fatal1ty X370 Gaming-ITX/ac User Manual

English
6
1.3 Motherboard Layout
BIOS
ROM
ATXPWR1
CLR CMO S1
1
1
USB _3_ 4
HD_ AUD IO 1
1
CPU _FA N1
RJ-45 LAN
SOCKET AM4
HDMI2
ATX1 2V 1
Ultra M.2
PCIe Gen3 x4
USB3 _3_4
1
CHA _FA N2
HDLE D RE SET
PLED P WRB TN
PANE L1
1
RoHS
DDR4_A1 (64 bit, 288-pin module)
DDR4_B1 (64 bit, 288-pin modul e)
AMD
Promontory
X370
U SB 3.0
T: USB1
B : USB2
AMD _FAN _LE D1
1
LPC 1
1
X370 Gaming-ITX/ac
PCIE1
CHA _FA N/ W_P UM P
USB 3. 0
T: US B31 _TA _1
B: USB 31 _TC _1
USB 2.0
T: USB1
B: USB2
PS2
Keyb oar d
/Mou se
HDMI1
Top:
Central/Bass
Cent er:
REAR SP K
Top:
LINE IN
Cent er:
FRON T
Bott om:
Opti cal
SPDI F
Bott om:
MIC I N
USB _5
1
SPE AKE R1
1
M2_WIFI_1
SATA3 _2
SATA3 _4
SATA3 _1
SATA3 _3
Top Side View

ASROCK Fatal1ty X370 Gaming-ITX/ac Specifications

General

Audio chip	Realtek ALC1220
Certification	FCC, CE, ErP/EuP
Component for	PC
Power source type	ATX
Motherboard chipset	AMD X370
PC health monitoring	CPU, FAN, Temperature, Voltage
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Motherboard chipset family	AMD
Windows operating systems supported	Windows 10 Education x64, Windows 10 Enterprise x64, Windows 10 Home x64, Windows 10 Pro x64
Cables included	SATA
Drivers included	Yes
LAN controller	Intel® I211-AT
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Ethernet interface type	Gigabit Ethernet
PS/2 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Number of SATA III connectors	4
BIOS type	UEFI AMI
ACPI version	5.1
BIOS memory size	128 Mbit
Processor socket	Socket AM4
Compatible processor series	AMD A, AMD Athlon, AMD Athlon X4, AMD Ryzen 3, AMD Ryzen 3 2nd Gen, AMD Ryzen 3 3rd Gen, AMD Ryzen 5, AMD Ryzen 5 2nd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7, AMD Ryzen 7 2nd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
DirectX version	12.0
Maximum resolution	4096 x 2160 pixels
Maximum graphics card memory	2048 MB
Memory channels	Dual-channel
Memory slots type	DIMM
Supported memory types	DDR4-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	2133, 2400, 2667, 2933, 3200, 3466 MHz
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	170 mm
