ASROCK FM2A88M Pro3 Plus User Manual

3
English
FM2A88M Pro3+
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 CPU Fan Connector (CPU_FAN1)
3 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
4 2 x 240-pin DDR3 DIMM Slots (DDR3_A2, DDR3_B2)
5 ATX Power Connector (ATXPWR1)
6 TPM Header (TPMS1)
7 Chassis Speaker Header (SPEAKER1)
8 SATA3 Connector (SATA_8)
9 SATA3 Connector (SATA_7)
10 Chassis Fan Connector (CHA_FAN1)
11 SATA3 Connector (SATA_6)
12 SATA3 Connector (SATA_5)
13 SATA3 Connector (SATA_4)
14 SATA3 Connector (SATA_3)
15 SATA3 Connector (SATA_2)
16 SATA3 Connector (SATA_1)
17 System Panel Header (PANEL1)
18 USB 2.0 Header (USB_6_7)
19 USB 2.0 Header (USB_8_9)
20 USB 3.0 Header (USB_10_11)
21 Front Panel Audio Header (HD_AUDIO1)
22 Clear CMOS Jumper (CLRCMOS1)
23 Chassis Intrusion Header (CI1)

ASROCK FM2A88M Pro3 Plus Specifications

General

Brand	ASROCK
Model	FM2A88M Pro3 Plus
Category	Motherboard
Language	English
