No. Description
1 Chassis/Waterpump Fan Connector (CHA_FAN1/WP)
2 CPU Fan Connector (CPU_FAN1)
3 ATX 12V Power Connector (ATX12V1)
4 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
5 ATX Power Connector (ATXPWR1)
6 USB 2.0 Header (USB_56)
7 USB 3.2 Gen1 Header (USB3_12)
8 SATA3 Connector (SATA3_1)
9 SATA3 Connector (SATA3_0)
10 SATA3 Connector (SATA3_3)
11 SATA3 Connector (SATA3_2)
12 Front Panel Type C USB 3.2 Gen1 Header (F_USB3_TC_1)
13 System Panel Header (PANEL1)
14 Chassis Speaker Header (SPEAKER1)
15 Chassis Fan Connector (CHA_FAN2)
16 Front Panel Audio Header (HD_AUDIO1)
17 Clear CMOS Jumper (CLRMOS1)
18 RGB LED Header (RGB_LED1)
19 Addressable LED Header (ADDR_LED1)
