ASROCK H81M-ITX/WiFi User Manual

2
English
No. Description
1 CPU Fan Connector (CPU_FAN1)
2 ATX 12V Power Connector (ATX12V1)
3 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
4 Clear CMOS Jumper (CLRCMOS1)
5 Chassis Intrusion Header (CI1)
6 ATX Power Connector (ATXPWR1)
7 TPM Header (TPMS1)
8 USB 2.0 Header (USB_6_7)
9 System Panel Header (PANEL1)
10 USB 2.0 Header (USB_4_5)
11 SATA3 Connector (SATA3_0)
12 SATA3 Connector (SATA3_1)
13 SATA2 Connector (SATA_2)
14 SATA2 Connector (SATA_3)
15 Front Panel Audio Header (HD_AUDIO1)
16 Chassis Fan Connector (CHA_FAN1)

ASROCK H81M-ITX/WiFi Specifications

General

Brand	ASROCK
Model	H81M-ITX/WiFi
Category	Motherboard
Language	English
