Page #130 background imageLoading...
Page #130 background image
H81M-ITX
129
繁體中文
接頭
• 1 x 機殼防護標頭
• 1 x TPM 標頭
• 1 x CPU 風扇接頭 (4-pin)
• 1 x 機殼風扇接頭 (4-pin)
• 1 x 24 pin ATX 電源接頭
• 1 x 4 pin 12V 電源接頭
• 1 x 前面板音訊接頭
• 1 x USB 2.0 排針 ( 支援 2 USB 2.0 連接埠 )
BIOS 功能
• 32Mb AMI UEFI Legal BIOS 多語 GUI 支援
• ACPI 1.1 符合喚醒自動開機
• 支援 SMBIOS 2.3.1
• CPUDRAMPCH 1.05VPCH 1.5V 電壓多重調整
支援 CD
• 驅動程式、公用程式、防毒軟體 ( 試用版 )CyberLink
MediaEspresso 6.5 TrialGoogle Chrome 瀏覽器及工具列、
Start8 (30 天試用 )
硬體監視器
• CPU /機殼溫度感應
• CPU /機殼轉速計
• CPU /機殼靜音風扇(允許按照 CPU 溫度自動調整機殼
風扇速度)
• CPU /機殼風扇多重速度控制
• 機殼開啟偵測
• 電壓監控:+12V+5V+3.3VCPU Vcore
作業系統
• 相容 Microso® Windows® 8 / 8 64 位元 / 7 / 7 64 位元
認證
• FCCCEWHQL
• ErP/EuP Ready(需具備 ErP/EuP ready 電源供應器)
