ASROCK H81M-ITX Installation Guide

8
English
Storage
•
2 x SATA3 6.0 Gb/s connectors, support NCQ, AHCI and Hot
Plug
•
1 x eSATA connector, supports NCQ, AHCI and Hot Plug
Connector
•
1 x Chassis Intrusion header
•
1 x TPM header
•
1 x CPU Fan connector (4-pin)
•
1 x Chassis Fan connector (4-pin)
•
1 x 24 pin ATX power connector
•
1 x 4 pin 12V power connector
•
1 x Front panel audio connector
•
1 x USB 2.0 header (supports 2 USB 2.0 ports)
BIOS
Feature
•
32Mb AMI UEFI Legal BIOS with Multilingual GUI support
•
ACPI 1.1 Compliance Wake Up Events
•
SMBIOS 2.3.1 Support
•
CPU, DRAM, PCH 1.05V, PCH 1.5V Voltage Multi-adjust-
ment
Support
CD
•
Drivers, Utilities, AntiVirus Soware (Trial Version),
CyberLink MediaEspresso 6.5 Trial, Google Chrome Browser
and Toolbar, Start8 (30 days trial)
Hardware
Monitor
•
CPU/Chassis Temperature Sensing
•
CPU/Chassis Tachometer
•
CPU/Chassis Quiet Fan (Allow Chassis Fan Speed Auto-
Adjust by CPU Temperature)
•
CPU/Chassis Fan Multi-Speed Control
•
CASE OPEN detection
•
Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
OS
•
Microso® Windows® 8 / 8 64-bit / 7 / 7 64-bit compliant
Certica-
tions
•
FCC, CE, WHQL
•
ErP/EuP Ready (ErP/EuP ready power supply is required)
