ASROCK H81M-ITX - Chapter 1 Introduction

H81M-ITX
3
English
I/O Panel
No. Description No. Description
1 USB 2.0 Ports (USB_23) 9 Microphone (Pink)
2 VGA Port 10 Optical SPDIF Out Port
3 eSATA Connector*** 11 USB 2.0 Ports (USB_01)
4 LAN RJ-45 Port* 12 USB 3.0 Ports (USB3_12)
5 Central / Bass (Orange) 13 HDMI Port
6 Rear Speaker (Black) 14 DVI-D Port
7 Line In (Light Blue) 15 PS/2 Mouse/Keyboard Port
8 Front Speaker (Lime)**
5 7
1 2 3 4 6
9101112131415
8
