Français

Spécications

Plateforme

• Facteur de forme Micro ATX

• Condensateur résistant pour alimentation de processeur

Processeur

• Prend en charge les processeurs Intel® Core

i7/i5/i3/Xeon®/

Pentium®/Celeron® 4e, nouvelle 4e génération (socket 1150)

• Prend en charge la technologie Intel® Turbo Boost 2.0

Chipset

• Intel® H81

Mémoire

• Technologie mémoire double canal DDR3

• 2 x fentes DIMM DDR3

• Prend en charge les mémoires sans tampon non ECC DDR3

1600/1333/1066

• Capacité max. de la mémoire système : 16Go

• Prend en charge Intel® Extreme Memory Prole (XMP)1.3/1.2

Fente

d’expansion

• 1 x fente PCI Express 2.0 x 16 (PCIE2: mode x16)

• 1 x fente PCI Express 2.0 x 1

Graphiques

• La technologie Intel® HD Graphics Built-in Visuals et les

sorties VGA sont uniquement prises en charge par les

processeurs intégrant un contrôleur graphique.

• Prend en charge la technologie Intel® HD Graphics Built-in

Visuals : Intel® Quick Sync Video with AVC, MVC (S3D) and

MPEG-2 Full HW Encode1, Intel® InTru

3D, Intel® Clear

Video HD Technology, Intel® Insider

, Intel® HD Graphics

4400/4600

• Pixel Shader 5.0, DirectX 11.1

• Mémoire partagée max. 1024Mo

• Prend en charge le mode D-Sub avec une résolution maximale

de 1920x1200 @ 60Hz

Audio

• Audio 7.1 CH HD (codec audio Realtek ALC887)

* Pour congurer l’audio 7.1 CH HD, il est nécessaire d’utiliser

un module audio HD pour panneau frontal et d’activer la

fonction audio multicanal via le pilote audio.

• Supporte la protection contre les

Questions and Answers:

Need help?

Do you have a question about the ASROCK H81M-VG4 R3.0 and is the answer not in the manual?

ASROCK H81M-VG4 R3.0 Specifications

General

Non-ECC	Yes
Internal memory	16 GB
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Supported memory clock speeds	1066, 1333, 1600 MHz
Certification	FCC, CE, WHQL, ErP/EuP ready
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H81
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Motherboard chipset family	Intel
Processor socket	LGA 1150 (Socket H3)
Compatible processor series	Intel Celeron, Intel Pentium
BIOS type	UEFI AMI
ACPI version	1.1
BIOS memory size	32 Mbit
Maximum resolution	1920 x 1080 pixels
LAN controller	Realtek RTL8111C
Ethernet interface type	Gigabit Ethernet
PCI Express x1 (Gen 2.x) slots	1
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
Supported storage drive interfaces	SATA II, SATA III
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cables included	SATA
Bundled software	- ASRock Disk Health Report - ASRock USB Key - ASRock APP Charger - ASRock XFast LAN - ASRock XFast RAM - ASRock Fast Boot (Fast Boot, Restart to UEFI) - ASRock Interactive UEFI - ASRock UEFI Guide - ASRock Instant Flash - ASRock Internet Flash - ASRock Crashless BIOS - ASRock UEFI Tech Service - ASRock Easy Driver Installer
Harmonized System (HS) code	84733020
