Page #22 background imageLoading...
Page #22 background image
20
Italiano
LAN
• PCIE x1 Gigabit LAN 10/100/1000 Mb/s
• Realtek RTL8111C
• Supporta Wake-On-LAN
• Supporto la protezione da fulmini/scariche elettrostatiche
(ESD) (protezione completa ASRock dai picchi di lcorrente)
• Supporta il rilevamento cavo LAN
• Supporta PXE
I/O pannello
posteriore
• 1 x porta mouse PS/2
• 1 x porta tastiera PS/2
• 1 x porta D-Sub
• 2 x porte USB 2.0 (supporto protezione da scariche
elettrostatiche (ESD) (protezione completa ASRock dai picchi
di corrente))
• 2 x porte USB 3.0 (supporto protezione da scariche
elettrostatiche (ESD) (protezione completa ASRock dai picchi
di corrente))
• 1 x porta LAN RJ-45 con LED (ACT/LINK LED e SPEED
LED)
• Jack audio HD: ingresso linea/altoparlante anteriore/
microfono
Archiviazione
• 2 x connettori SATA3 6,0 Gb/s, supporta le funzioni NCQ,
AHCI e “Hot Plug
• 2 x connettori SATA2 3,0 Gb/s, supporta le funzioni NCQ,
AHCI e “Hot Plug
Connettore
• 1 x header di intrusione nello chassis
• 1 x header TPM
• 1 x connettore ventola CPU (4 pin)
• 1 x connettore ventola chassis (4 pin)
• 1 x connettore alimentazione ATX a 24 pin
• 1 x connettore alimentazione da 12 V a 4 pin
• 1 x connettore audio pannello anteriore
• 2 x header USB 2.0 (supporto 4 porte USB 2.0) (supporto
protezione da scariche elettrostatiche (ESD) (protezione
completa ASRock dai picchi di corrente))
Caratteristi-
che del BIOS
• BIOS legale AMI UEFI con supporto GUI multilingue
• Eventi di wake up conformi ad ACPI 1.1
• Supporto SMBIOS 2.3.1
• Multiregolazione tensione CPU, DRAM

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK H81M-VG4 R3.0 and is the answer not in the manual?

ASROCK H81M-VG4 R3.0 Specifications

General IconGeneral
Non-ECCYes
Internal memory16 GB
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots2
Supported memory typesDDR3-SDRAM
Supported memory clock speeds1066, 1333, 1600 MHz
CertificationFCC, CE, WHQL, ErP/EuP ready
Component forPC
Power source typeATX
Motherboard chipsetIntel® H81
Audio output channels7.1 channels
Motherboard form factormicro ATX
Motherboard chipset familyIntel
Processor socketLGA 1150 (Socket H3)
Compatible processor seriesIntel Celeron, Intel Pentium
BIOS typeUEFI AMI
ACPI version1.1
BIOS memory size32 Mbit
Maximum resolution1920 x 1080 pixels
LAN controllerRealtek RTL8111C
Ethernet interface typeGigabit Ethernet
PCI Express x1 (Gen 2.x) slots1
USB 3.2 Gen 1 (3.1 Gen 1) connectors0
Supported storage drive interfacesSATA II, SATA III
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cables includedSATA
Bundled software- ASRock Disk Health Report - ASRock USB Key - ASRock APP Charger - ASRock XFast LAN - ASRock XFast RAM - ASRock Fast Boot (Fast Boot, Restart to UEFI) - ASRock Interactive UEFI - ASRock UEFI Guide - ASRock Instant Flash - ASRock Internet Flash - ASRock Crashless BIOS - ASRock UEFI Tech Service - ASRock Easy Driver Installer
Harmonized System (HS) code84733020
Weight and Dimensions IconWeight and Dimensions
Width- mm
