Page #24 background imageLoading...
Page #24 background image
22
Español
Especicaciones
Plataforma
• Factor de forma Micro ATX
• Condensador sólido para alimentación de CPU
CPU
• Admite procesadores Intel® Core
TM
i7/i5/i3/Xeon®/Pentium®/
Celeron® (calo 1150) de la nueva 4ª y 4ª generación
• Compatible con la tecnología de Intel® Turbo Boost 2.0
Conjunto de
chips
• Intel® H81
Memoria
• Tecnología de memoria de Doble Canal DDR3
• 2 ranuras DDR3 DIMM
• Compatible con memoria no-ECC, sin búfer DDR3
1600/1333/1066
• Capacidad máxima de la memoria del sistema: 16GB
Compatible con Extreme Memory Prole (XMP)1.3/1.2 de
Intel®
Ranura de
expansión
• 1 ranura PCI Express 2.0 x16 (PCIE2: modo x16)
• 1 ranura PCI Express 2.0 x1
Grácos
• La Tecnología visual integrada de gcos HD de Intel®
y las salidas de VGA son compatibles únicamente con
procesadores con GPU integrado.
• Compatible con la Tecnología visual integrada de gcos
HD de Intel®: Intel® Quick Sync Video con AVC, MVC (S3D)
y MPEG-2 Full HW Encode1, Intel® InTru
TM
3D, Intel® Clear
Video HD Technology, Intel® Insider
TM
, Intel® HD Graphics
4400/4600
• Pixel Shader 5.0, DirectX 11.1
• Memoria compartida máxima: 1024MB
• Compatible con D-Sub con máxima resolución hasta
1920x1200 @ 60Hz
Audio
• 7.1 Audio CH HD (Realtek ALC887 Audio Codec)
* Para congurar 7.1 Audio CH HD, deberá utilizar un módulo
del panel frontal de audio HD y habilitar la característica de
audio multicanal a través del controlador de audio.
• Admite protección contra subidas de tensión (Protección
Integral contra Picos de ASRock)

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK H81M-VG4 R3.0 and is the answer not in the manual?

ASROCK H81M-VG4 R3.0 Specifications

General IconGeneral
Non-ECCYes
Internal memory16 GB
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots2
Supported memory typesDDR3-SDRAM
Supported memory clock speeds1066, 1333, 1600 MHz
CertificationFCC, CE, WHQL, ErP/EuP ready
Component forPC
Power source typeATX
Motherboard chipsetIntel® H81
Audio output channels7.1 channels
Motherboard form factormicro ATX
Motherboard chipset familyIntel
Processor socketLGA 1150 (Socket H3)
Compatible processor seriesIntel Celeron, Intel Pentium
BIOS typeUEFI AMI
ACPI version1.1
BIOS memory size32 Mbit
Maximum resolution1920 x 1080 pixels
LAN controllerRealtek RTL8111C
Ethernet interface typeGigabit Ethernet
PCI Express x1 (Gen 2.x) slots1
USB 3.2 Gen 1 (3.1 Gen 1) connectors0
Supported storage drive interfacesSATA II, SATA III
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cables includedSATA
Bundled software- ASRock Disk Health Report - ASRock USB Key - ASRock APP Charger - ASRock XFast LAN - ASRock XFast RAM - ASRock Fast Boot (Fast Boot, Restart to UEFI) - ASRock Interactive UEFI - ASRock UEFI Guide - ASRock Instant Flash - ASRock Internet Flash - ASRock Crashless BIOS - ASRock UEFI Tech Service - ASRock Easy Driver Installer
Harmonized System (HS) code84733020
