ASROCK K7VT4A PRO - Motherboard Layout

7
17.8cm (7.0 in)
DDR 1 (64/72 bit, 184-pin module)
DDR2 (64/72 bit, 184-pin module)
5
PCI2
PCI3
PCI4
PCI5
PCI1
25
1.5V_AGP1
USB67
1
18
SPEAKER1
1
HDLED RST
PLED PWRBTN
1
PANEL1
2MB
BIOS
22
FLOPPY1
SUPER
I/O
CLRCMOS2
VIA
VT8237
CPU_FAN1
CHA_FAN1
CMOS
BATTERY
PS2_USB_PWR1
1
IDE1 IDE2
USB2.0
5.1CH
ATA133
FSB400
K7VT4A PRO
VIA
KT400A
CHIPSET
ATXPWR1
AUX1
CD1
PARALLEL PORT
PS/2
MOUSE
PS/2
KEYBOARD
SERIAL
PORT
(COM1)
30.5cm (12.0 in)
LAN
PHY
AUDIO
CODEC
12
36
4
7
8
9
10
11
15
16
19
27
28
29
DDR400
AGP 8X
1
1
PWR_LED1
14
1
FSB_SEL0
1
1
FSB_SEL1
FSB_SEL2
1
1
1
1
FID3
FID2
FID1
FID0
FID4
1
J1
SOCKET 462
SATA2
SATA1
AUDIO1
1
GAME1
1
1
JUSB45
Top:
Line In
Center:
Line Out
Bottom:
Mic In
USB 2.0
T: U S B4
B: USB5
JR1 JL1
USB 2.0
T: U S B2
B: USB3
USB 2.0
T: U S B0
B: USB1
Top:
RJ-45
SATA
12
13
17
2021
23
24
26
1.3 Motherboard Layout
1 PS2_USB_PWR1 Jumper 15 Chassis Fan Connector (CHA_FAN1)
2 CPU Fan Connector (CPU_FAN1) 16 System Panel Connector (PANEL1)
3 CPU Socket 17 Chassis Speaker Connector (SPEAKER 1)
4 North Bridge Controller 18 USB 2.0 Connector (USB67, Blue)
5 184-pin DDR DIMM Slots (DDR1- 2) 19 Floppy Connector (FLOPPY1)
6 ATX Power Connector (ATXPWR1) 20 Internal Audio Connector: CD1 (Black)
7 Secondary IDE Connector (IDE2, Black) 21 Internal Audio Connector: AUX1 (White)
8 Primary IDE Connector (IDE1, Blue) 22 Clear CMOS Jumper (CLRCMOS2)
9 AGP Slot (1.5V_AGP1) 23 JR1 / JL1 Jumpers
10 FSB Select Jumpers 24 Front Panel Audio Connector (AUDIO1)
(FSB_SEL0, FSB_SEL1, FSB_SEL2) 25 PCI Slots (PCI1- 5)
11 South Bridge Controller 26 Game Port Connector (GAME1)
12 Primary Serial ATA Connector (SATA1) 27 Flash Memory
13 Secondary Serial ATA Connector (SATA2) 28 Shared USB 2.0 Header (JUSB45, Blue)
14 Power LED Connector (PWR_LED1) 29 J1 Jumper (FID0, FID1, FID2, FID3, FID4)
