BIOS SETUP UTILITY
Main
Advanced H/W Monitor Boot Security Exit
Overclocking may cause
damage to your CPU and
motherboard.
It should be done at
your own risk and
expense.
Select Screen
Select Item
Enter Go to Sub Screen
F1 General Help
F9 Load Defaults
F10 Save and Exit
ESC Exit
v02.54 (C) Copyright 1985-2005, American Megatrends, Inc.
OC Tweaker
CPU Configuration
CPU Frequency (MHz)
PCIE Frequency (MHz)
Overclock Mode
[200]
[100]
[Auto]
Spread Spectrum
Boot Failure Guard
Processor Maximum Multiplier
Processor Maximum Voltage
x11 2200 MHZ
1.450 V
[Auto]
[Enabled]
Multiplier/Voltage Change
Processor Multiplier
Processor Voltage
HT Bus Speed
HT Bus Width
CPU Thermal Throttle
[Manual]
[x11 2200 MHZ]
[1.400 V]
[Auto]
[Auto]
[Auto]
Memory Configuration
Processor Multiplier
This item will show when “Multiplier/Voltage Change” is set to [Manual];
otherwise, it will be hidden. The range of the value depends on the CPU
you adopt on this motherboard. However, for system stability, it is not
recommended to adjust the value of this item.
Processor Voltage
This item will show when “Multiplier/Voltage Change” is set to [Manual];
otherwise, it will be hidden. The range of the value depends on the CPU
you adopt on this motherboard. However, for safety and system stability,
it is not recommended to adjust the value of this item.
HT Bus Speed
This feature allows you selecting Hyper-Transport bus speed. Configura-
tion options: [Auto], [200 MHz], [400 MHz], [600 MHz], [800 MHz] and [1000
MHz]. The configuration options depend on the CPU you adopt.
HT Bus Width
This feature allows you selecting Hyper-Transport bus width. Configura-
tion options: [Auto], [8 Bit] and [16 Bit].
CPU Thermal Throttle
Use this to enable CPU internal thermal control mechanism to keep the CPU
from overheated. Configuration options: [Disabled], [Auto], [12.5%], [25%],
[37.5%], [50%], [62.5%], [75%] and [87.5%]. The default value is [Auto].
Memory Configuration
Memory Clock
This item can be set by the code using [Auto]. You can set one of the
standard values as listed: [133MHz DDR_266], [166MHz DDR_333)] and
[200MHz DDR_400].
DRAM Voltage
Use this to select DRAM voltage. Configuration options: [Auto], [2.60V] to
[2.95V]. The default value is [Auto].
