ASROCK N3700-ITX Manual

English
5
N3700-ITX
N3150-ITX
Chapter 1 Introduction
ank you for purchasing ASRock N3700-ITX / N3150-ITX motherboard, a reliable
motherboard produced under ASRock’s consistently stringent quality control.
It delivers excellent performance with robust design conforming to ASRock’s
commitment to quality and endurance.
1.1 Package Contents
•
ASRock N3700-ITX / N3150-ITX Motherboard (Mini-ITX Form Factor)
•
ASRock N3700-ITX / N3150-ITX Quick Installation Guide
•
ASRock N3700-ITX / N3150-ITX Support CD
•
2 x Serial ATA (SATA) Data Cables (Optional)
•
1 x I/O Panel Shield
•
1 x WiFi Module Screw
Because the motherboard specications and the BIOS soware might be updated, the
content of this documentation will be subject to change without notice. In case any
modications of this documentation occur, the updated version will be available on
ASRock’s website without further notice. If you require technical support related to
this motherboard, please visit our website for specic information about the model
you are using. You may nd the latest VGA cards and CPU support list on ASRock’s
website as well. ASRock website http://www.asrock.com.

ASROCK N3700-ITX Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	SO-DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM, DDR3L-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1600 MHz
Processor cores	4
Processor model	N3700
Processor socket	BGA 1170
Processor manufacturer	Intel
Compatible processor series	Not supported
Maximum number of SMP processors	1
Processor frequency	1.6 GHz
Number of Parallel ATA connectors	-
Supported storage drive interfaces	SATA III
Headphone outputs	5
DisplayPort version	1.1
eSATA ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Realtek RTL8111GR
Ethernet interface type	Gigabit Ethernet
Audio chip	Realtek ALC892
Certification	- FCC, CE, WHQL\\r - ErP/EuP ready (ErP/EuP ready power supply is required)
Component for	PC
Power source type	ATX
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
DirectX version	11.1
Maximum resolution	3840 x 2160 pixels
Number of displays supported	3
BIOS type	UEFI AMI
BIOS memory size	64 Mbit
Cables included	SATA

Weight and Dimensions

Width	- mm
