ASROCK N3700-ITX Manual

English
6
1.2 Specications
Platform
•
Mini-ITX Form Factor
•
Solid Capacitor design
•
High Density Glass Fabric PCB
CPU
•
Intel® Quad-Core Pentium® Processor N3700 (up to 2.4 GHz)
(for N3700-ITX)
•
Intel® Quad-Core Processor N3150 (up to 2.08 GHz)
(for N3150-ITX)
Memory
•
Dual Channel DDR3/DDR3L Memory Technology
•
2 x DDR3/DDR3L SO-DIMM Slots
•
Supports DDR3/DDR3L 1600/1066 non-ECC, un-buered
memory
•
Max. capacity of system memory: 16GB
(see CAUTION)
* If only one SO-DIMM module is installed, please install it into
DDR3_A1.
Expansion
Slot
•
1 x PCI Express 2.0 x1 Slot
•
1 x Half-size Mini-PCI Express Slot
Graphics
•
Intel® 8
th
generation (Gen 8) graphics: up to 16 EUs inside
(for N3700-ITX)
•
Intel® 8
th
generation (Gen 8) graphics: up to 12 EUs inside
(for N3150-ITX)
•
DirectX 11.1, Pixel Shader 5.0
•
ree graphics output options: DVI-D, HDMI and
DisplayPort 1.1a
•
Supports Triple Monitor
•
Supports HDMI with max. resolution up to 4K x 2K
(3840x2160) @ 30Hz or 2560x1600 @ 60Hz
•
Supports DVI-D with max. resolution up to 1920x1200 @
60Hz
•
Supports DisplayPort 1.1a with max. resolution up to 4K x 2K
(3840x2160) @ 30Hz or 2560x1600 @ 60Hz
•
Supports Auto Lip Sync, xvYCC and HBR (High Bit Rate
Audio) with HDMI Port (Compliant HDMI monitor is
required)
•
Supports HW Accelerated Decoders: H.264 @ level 5.2,
H.265/HEVC @ level 5 (GPU accelerated), JPEG, VP8

ASROCK N3700-ITX Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	SO-DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM, DDR3L-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1600 MHz
Processor cores	4
Processor model	N3700
Processor socket	BGA 1170
Processor manufacturer	Intel
Compatible processor series	Not supported
Maximum number of SMP processors	1
Processor frequency	1.6 GHz
Number of Parallel ATA connectors	-
Supported storage drive interfaces	SATA III
Headphone outputs	5
DisplayPort version	1.1
eSATA ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Realtek RTL8111GR
Ethernet interface type	Gigabit Ethernet
Audio chip	Realtek ALC892
Certification	- FCC, CE, WHQL\\r - ErP/EuP ready (ErP/EuP ready power supply is required)
Component for	PC
Power source type	ATX
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
DirectX version	11.1
Maximum resolution	3840 x 2160 pixels
Number of displays supported	3
BIOS type	UEFI AMI
BIOS memory size	64 Mbit
Cables included	SATA

Weight and Dimensions

Width	- mm
