ASROCK N68C-S UCC User Manual

w w w. a s ro ck. c o m
NVIDIA
®
GeForce 7025 / nForce 630a Chipset
N68C-S UCC
World's First NVIDIA Chipset Motherboard
Supports Unlock CPU Core
Step 1 Step 2
Step 3 Step 4
Step 5
Press “F2 or DEL” to enter the BIOS.
CPU Information Under OS
“ASRock UCC” set to Enabled.
Press “F10” to save change and exit.
Choose the “OC Tweaker” page and
“ASRock UCC” option!
Press “F2 or DEL” to enter the BIOS.
Processor Type unlock to “AMD Phenom II X4 05e”
under “Main” page.
880GM Pro3
Unlock
100%
CPU potential
up to 6 Cores
CPU Performance Boost!
ASRock UCC
(Unlock CPU Core)
With ASRock UCC , one simple click in BIOS can unlock CPU core to enjoy an instant performance boost.
AMD CPU Core X2/X3AMD CPU Core X2/X3
AMD CPU Core X4AMD CPU Core X4
X4X4
X6X6
Unlock
100%
CPU potential
up to 6 Cores
CPU Performance Boost!
Before -
UCC not enabled, Cores: 4
After -
UCC enabled, Cores: 6
Simply enables UCC
function in BIOS
Step 6
Before and After UCC

ASROCK N68C-S UCC Specifications

General

Non-ECC	Yes
Number of memory slots	2
Maximum internal memory	8 GB
Processor manufacturer	AMD
USB 2.0 connectors	3
Number of SATA connectors	4
I/O ports	1 x ATA133 IDE
Controller interface type	SATAII
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1705
Certification	FCC, CE, WHQL
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Compatible operating systems	Windows 7/7 64-bit/Vista/Vista 64-bit/XP/XP 64-bit
Maximum graphics card memory	256 MB
RAID levels	0, 1, 0+1, 5, JBOD
Networking features	Ethernet
BIOS type	AMI
ACPI version	1.1
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	208 mm
Width	244 mm
