ASROCK P67 PRO3 Quick Installation Guide

Installing OS on a HDD Larger Than 2TB
This motherboard is adopting UEFI BIOS that allows Windows
®
OS to be
installed on a large size HDD (>2TB). Please follow below procedure to
install the operating system.
1. Please make sure to use Windows
®
Vista
TM
64-bit (with SP1 or
above) or Windows
®
7 64-bit.
2. Set AHCI Mode in UEFI Setup Utility > Advanced > Storage
Confi guration > SATA Mode.
3. Press F11 to launch boot menu at system POST.
4. Choose the item “UEFI:xxx“ to boot. (“xxx” is the device which contains
your Windows
®
installation fi les. Normally it is an optical drive.)
5. Start Windows
®
installation.

ASROCK P67 PRO3 Specifications

General

Form Factor	ATX
Chipset	Intel P67
Socket	LGA 1155
Memory Slots	4 x DIMM
Maximum Memory	32GB
Memory Type	DDR3
PCI Express x16	2
PCI Express x1	2
PCI Slots	2
SATA 6Gb/s	2
SATA 3Gb/s	4
USB 2.0 Ports	8
USB 3.0 Ports	2
LAN	Gigabit Ethernet
Audio	7.1 Channel HD Audio
