ASROCK PHANTOM GAMING B650E PG-ITX WiFi - Page 12

English
8
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 Addressable LED Header (ADDR_LED1)
3 Addressable LED Header (ADDR_LED2)
4 CPU Fan Connector (CPU_FAN1)
5 CPU/Water Pump Fan (M.2 Fan) Connector (CPU_FAN2/WP)
6 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1)
7 ATX Power Connector (ATXPWR1)
8 SATA3 Connector (SATA3_2)
9 SATA3 Connector (SATA3_1)
10 USB 3.2 Gen1 Header (USB32_4_5)
11 System Panel Header (PANEL1)
12 USB 2.0 Header (USB_5_6)
13 Front Panel Type C USB 3.2 Gen2x2 Header (USB32_TC2)
14 Clear CMOS Jumper (CLRCMOS1)
15 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
16 Chassis Speaker Header (SPEAKER1)
17 Front Panel Audio Header (HD_AUDIO1)
18 eDP Signal Connector (EDP1)
