ASROCK PHANTOM GAMING B650E PG-ITX WiFi User Manual

English
4
Storage
CPU:
•
1 x Blazing M.2 Socket (M2_1, Key M), supports type 2280
PCIe Gen5x4 (128 Gb/s) mode*
•
1 x Hyper M.2 Socket (M2_2, Key M), supports type 2280
PCIe Gen4x4 (64 Gb/s) mode*
Chipset:
•
2 x SATA3 6.0 Gb/s Connectors
* Supports NVMe SSD as boot disks
* Supports ASRock U.2 Kit
RAID
•
Supports RAID 0 and RAID 1 for SATA storage devices
•
Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe
storage devices*
* Requires additional M.2 NVMe expansion cards to support
RAID 10
Connector
•
1 x eDP Signal Connector
•
2 x Addressable LED Headers*
•
1 x CPU Fan Connector (4-pin)**
•
1 x CPU/Water Pump Fan (M.2 Fan) Connector (4-pin)
(Smart Fan Speed Control)***
•
1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan
Speed Control)****
•
1 x 24 pin ATX Power Connector (Hi-Density Power Con-
nector)
•
1 x 8 pin 12V Power Connector (Hi-Density Power Connec-
tor)
•
1 x Front Panel Audio Connector (15μ Gold Audio Connec-
tor)
•
1 x USB 2.0 Header (Supports 2 USB 2.0 ports)
•
1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
•
1 x Front Panel Type C USB 3.2 Gen2x2 Header (20 Gb/s)
(ReDriver)
* Support in total up to 5V/3A, 15W LED Strip
** CPU_FAN1 supports the fan power up to 1A (12W).
*** CPU_FAN2/WP (M.2 fan connector) supports the fan
power up to 2A (24W).
