ASROCK Q1900DC-ITX - Page 4

English
2
No. Description
1 CPU Fan Connector (CPU_FAN1)
2 2 x 204-pin DDR3 SO-DIMM Slots (DDR3_A1, DDR3_B1)
3 System Panel Header (PANEL1)
4 USB 2.0 Header (USB1_2)
5 USB 3.0 Header (USB3_1_2)
6 SATA Power Connector (SATA_PWR2)
7 SATA2 Connector (SATA2_2)
8 SATA Power Connector (SATA_PWR1)
9 Chassis Fan Connector (CHA_FAN1)
10 SATA2 Connector (SATA2_1)
11 TPM Header (TPMS1)
12 Chassis Speaker Header (SPEAKER1)
13 COM Port Header (COM1)
14 Chassis Intrusion Header (CI1)
15 Clear CMOS Jumper (CLRCMOS1)
16 SATA3 Connector (SATA3_A1)
17 Print Port Header (LPT1)
18 SATA3 Connector (SATA3_A2)
19 Front Panel Audio Header (HD_AUDIO1)
20 SPDIF Out Connector (SPDIF_OUT1)
