ASROCK Q1900M User Manual

Q1900M / D1800M
5
English
1.3 Motherboard Layout
RoHS
USB 3.0
CMOS
Battery
Super
I/O
LAN
AUDIO
CODEC
64Mb
BIOS
PS2
Keyboard
PS2
Mouse
VGA1
DVI1
USB 2.0
T: USB2
B: USB3
HDMI1
Top:
RJ-45
USB 3.0: USB1 USB 2.0: USB0
Top :
LINE IN
Cent er:
FRON T
Bott om:
MIC IN
PCIE1
PCIE2
PCIE3
ATXPWR1
1
HD_ AU DI O1
CI1
1
1
TPM S1
1
LPT1
COM 1
1
1
USB4_5
1
SPEA KER 1
CL R CM OS 1
1
1
USB6
HDL ED RESET
PLE D PWR BTN
PANE L1
1
SATA2 _2
SATA2 _1
CPU_ FAN 1
D DR3_A1 (64 bit, 240-pin module)
D DR3_B1 (64 bit, 240-pin modul e)

ASROCK Q1900M Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333 MHz
Processor manufacturer	Intel
Compatible processor series	-
Number of COM connectors	1
USB 3.2 Gen 1 (3.1 Gen 1) connectors	0
Supported storage drive interfaces	SATA II
USB 2.0 ports quantity	3
Bluetooth	No
LAN controller	Realtek RTL8111GR
Audio chip	Realtek ALC662
Certification	- FCC, CE, WHQL - ErP/EuP ready
Component for	PC
Power source type	ATX
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Maximum resolution	1920 x 1200 pixels
BIOS type	UEFI AMI
ACPI version	1.1
BIOS memory size	64 Mbit
Trial software	AntiVirus Software, Start8
Cables included	SATA
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	- mm
