ASROCK Q2900-ITX - I;O Panel

Q2900-ITX
7
English
1.4 I/O Panel
No. Description No. Description
1 PS/2 Mouse Port 8 Front Speaker (Lime)**
2 D-Sub Port 9 Microphone (Pink)
3 USB 2.0 Ports (USB_34) 10 Optical SPDIF Out Port
4 LAN RJ-45 Port* 11 USB 3.0 Ports (USB3_34)
5 Central / Bass (Orange) 12 HDMI Port
6 Rear Speaker (Black) 13 DVI-D Port
7 Line In (Light Blue) 14 PS/2 Keyboard Port
1 3 4
111214
2
13
910
6
5
8
7
