No. Description
1 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_A2)
2 Clear CMOS Jumper (CLRCMOS1)
3 Chassis Fan Connector (CHA_FAN1)
4 ATX Power Connector (ATXPWR1)
5 System Panel Header (PANEL1)
6 SATA3 Connector (SATA3_1)
7 SATA3 Connector (SATA3_2)
8 Chassis Speaker Header (SPEAKER1)
9 CPU Fan Connector (CPU_FAN1)
10 USB 2.0 Header (USB4_5)
11 USB 2.0 Header (USB2_3)
12 TPM Header (TPMS1)
13 Front Panel Audio Header (HD_AUDIO1)
