5
English
VisionX Series
NOTE
1. SATA and Power Connections
2. Fan Connection
SAT
A&Power C
onnections
ODD
HDD
ConnecttoATX5V Power Connector(3)
Connectto SATAConnector(4)
ConnecttoHDD
ConnecttoODD
Connectto SATAConnector(1)
Fanconnector
Rotation
+12V
Ground
