ASROCK Z170 Pro4 User Manual

2
English
1.2 Specications
Platform
•
ATX Form Factor
•
High Density Glass Fabric PCB
CPU
•
Supports 6
th
Generation Intel® Core
TM
i7/i5/i3/Pentium®/
Celeron® Processors (Socket 1151)
•
Digi Power design
•
10 Power Phase design
•
Supports Intel® Turbo Boost 2.0 Technology
•
Supports Intel® K-Series unlocked CPUs
•
Supports ASRock BCLK Full-range Overclocking
Chipset
•
Intel
®
Z170
Memory
•
Dual Channel DDR4 Memory Technology
•
4 x DDR4 DIMM Slots
•
Supports DDR4 3200+(OC)*/2933(OC)/2800(OC)/2400
(OC)/2133 non-ECC, un-buered memory
* Please refer to Memory Support List on ASRock's website for
more information. (http://www.asrock.com/)
•
Max. capacity of system memory: 64GB
•
Supports Intel® Extreme Memory Prole (XMP) 2.0
Expansion
Slot
•
2 x PCI Express 3.0 x16 Slots (PCIE2: x16 mode; PCIE4: x4
mode)
•
3 x PCI Express 3.0 x1 Slots (Flexible PCIe)
•
Supports AMD Quad CrossFireX
TM
and CrossFireX
TM
Graphics
•
Intel® HD Graphics Built-in Visuals and the VGA outputs
can be supported only with processors which are GPU
integrated.
•
Supports Intel® HD Graphics Built-in Visuals : Intel® Quick
Sync Video with AVC, MVC (S3D) and MPEG-2 Full
HW Encode1, Intel® InTru
TM
3D, Intel® Clear Video HD
Technology, Intel® Insider
TM
, Intel® HD Graphics 510/530
•
Pixel Shader 5.0, DirectX 12
•
Max. shared memory 1792MB

ASROCK Z170 Pro4 Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2933, 2400, 3200, 3600, 2800 MHz
Processor socket	LGA 1151 (Socket H4)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
Certification	FCC, CE, WHQL, ErP/EuP
Component for	PC
Motherboard chipset	Intel® Z170
Audio output channels	7.1 channels
Motherboard form factor	ATX
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Enterprise, Windows 7 Home Basic x64, Windows 10 Home, Windows 7 Home Premium, Windows 8.1, Windows 10 Pro, Windows 7 Home Premium x64, Windows 8.1 x64, Windows 10 Enterprise, Windows 7 Professional, Windows 8.1 Pro, Windows 10 Education, Windows 7 Professional x64, Windows 8.1 Pro x64, Windows 10 Home x64, Windows 7 Ultimate, Windows 8.1 Enterprise, Windows 10 Pro x64, Windows 7 Ultimate x64, Windows 8.1 Enterprise x64, Windows 10 Enterprise x64, Windows 10 Education x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Enterprise x64
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	16 Mbit
DirectX version	12.0
Maximum resolution	4096 x 2160 pixels
Maximum graphics card memory	1792 MB
Parallel processing technology support	4-Way CrossFireX, 2-Way CrossFireX
LAN controller	Intel® I219-V
Ethernet interface type	Fast Ethernet, Gigabit Ethernet
PCI Express x1 (Gen 3.x) slots	3
PCI Express x16 (Gen 3.x) slots	2
Number of SATA II connectors	0
Number of SATA III connectors	6
Supported storage drive interfaces	SATA III
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Cables included	SATA
