ASROCK Z690 PG Riptide - Page 11

English
4
Storage
•
8 x SATA3 6.0 Gb/s Connectors*
* If M2_3 is occupied by a SATA-type M.2 device, SATA3_7 will
be disabled.
•
1 x Hyper M.2 Socket (M2_1, Key M), supports type
2260/2280 PCIe Gen4x4 (64 Gb/s) mode**
•
1 x Hyper M.2 Socket (M2_2, Key M), supports type
2242/2260/2280 PCIe Gen4x4 (64 Gb/s) mode**
•
1 x Ultra M.2 Socket (M2_3, Key M), supports type
2260/2280/22110 SATA3 6.0 Gb/s & PCIe Gen3x4 (32 Gb/s)
modes**
** Supports Intel® Optane
TM
Technology (M2_2 and M2_3 only)
** Supports Intel® Volume Management Device (VMD)
** Supports NVMe SSD as boot disks
** Supports ASRock U.2 Kit
RAID
•
Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA
storage devices
•
Supports RAID 0, RAID 1 and RAID 5 for M.2 NVMe stor-
age devices
Connector
•
1 x SPI TPM Header
•
1 x Power LED and Speaker Header
•
1 x RGB LED Header
* Supports in total up to 12V/3A, 36W LED Strip
•
3 x Addressable LED Headers
* Support in total up to 5V/3A, 15W LED Strip
•
1 x CPU Fan Connector (4-pin)
* e CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
•
1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan
Speed Control)
* e CPU/Water Pump Fan supports the water cooler fan of
maximum 2A (24W) fan power.
•
4 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan
Speed Control)
* e Chassis/Water Pump Fan supports the water cooler fan of
maximum 2A (24W) fan power.
* CPU_FAN2/WP and CHA_FAN1~4/WP can auto detect if
3-pin or 4-pin fan is in use.
•
1 x 24 pin ATX Power Connector
