Page #29 background imageLoading...
Page #29 background image
21
English
Z690 Steel Legend WiFi 6E/D5
Z690 Steel Legend/D5
2.4 Expansion Slots (PCIe Slots)
ere are 5 PCIe slots on the motherboard.
PCIe slots:
PCIE1 (PCIe 3.0 x1 slot) is used for PCIe x1 lane width cards.
PCIE2 (PCIe 5.0 x16 slot) is used for PCIe x16 lane width graphics cards.
PCIE3 (PCIe 4.0 x16 slot) is used for PCIe x4 lane width graphics cards.
PCIE4 (PCIe 3.0 x1 slot) is used for PCIe x1 lane width cards.
PCIE5 (PCIe 3.0 x16 slot) is used for PCIe x4 lane width graphics cards.
PCIe Slot Congurations
Before installing an expansion card, please make sure that the power supply is
switched o or the power cord is unplugged. Please read the documentation of the
expansion card and make necessary hardware settings for the card before you start
the installation.
For a better thermal environment, please connect a chassis fan to the motherboard’s
chassis fan connector (CHA_FAN1~5/WP) when using multiple graphics cards.
PCIE2 PCIE3 PCIE5
Single Graphics Card Gen5x16 N/A N/A
Two Graphics Cards in
CrossFire
TM
Mode
Gen5x16 Gen4x4 N/A
Two Graphics Cards in
CrossFire
TM
Mode
Gen5x16 N/A Gen3x4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK Z690 Steel Legend/D5 and is the answer not in the manual?

ASROCK Z690 Steel Legend/D5 Specifications

General IconGeneral
Processor socketLGA 1700
Processor manufacturerIntel
Compatible processor seriesIntel Core i3, Intel Core i5, Intel Core i7, Intel Core i9
Non-ECCYes
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots4
Supported memory typesDDR5-SDRAM
Maximum internal memory128 GB
RAID levels0, 1, 5, 10
Supported storage drive typesHDD & SSD
Number of storage drives supported11
Supported storage drive interfacesM.2, SATA III
Parallel processing technology support-
USB 2.0 connectors2
Thunderbolt headers1
Number of SATA III connectors8
USB connector typeUSB Type-A, USB Type-C
DisplayPort version1.4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity9
Wi-FiNo
LAN controllerDragon RTL8125BG
Ethernet interface type2.5 Gigabit Ethernet
Audio chipRealtek ALC897
Component forPC
Motherboard chipsetIntel Z690
Audio output channels7.1 channels
Motherboard form factorATX
Windows operating systems supportedWindows 10 x64, Windows 11 x64
Number of M.2 (M) slots3
BIOS typeUEFI AMI
ACPI version6.0
BIOS memory size256 Mbit
System Management BIOS (SMBIOS) version2.7
Harmonized System (HS) code84733020
Weight and Dimensions IconWeight and Dimensions
Depth244 mm
Width305 mm
