ASROCK Z690M PG Riptide/D5 Manual

English
2
No. Description
1 8 pin 12V Power Connector (ATX12V1)
2 4 pin 12V Power Connector (ATX12V2)
3 CPU Fan Connector (CPU_FAN1)
4 2 x 288-pin DDR5 DIMM Slots (DDR5_A1, DDR5_B1)
5 2 x 288-pin DDR5 DIMM Slots (DDR5_A2, DDR5_B2)
6 Chassis/Water Pump Fan Connector (CHA_FAN3/WP)
7 CPU/Water Pump Fan Connector (CPU_FAN2/WP)
8 Addressable LED Header (ADDR_LED3)
9 Addressable LED Header (ADDR_LED2)
10 Post Status Checker (PSC)
11 ATX Power Connector (ATXPWR1)
12 USB 3.2 Gen1 Header (USB3_6_7)
13 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
14 Front Panel Type C USB 3.2 Gen1 Header (F_USB31_TC_1)
15 SATA3 Connector (SATA3_0) (Upper), SATA3 Connector (SATA3_1) (Lower)
16 SATA3 Connector (SATA3_2) (Upper), SATA3 Connector (SATA3_3) (Lower)
17 System Panel Header (PANEL1)
18 SPI TPM Header (SPI_TPM_J1)
19 Power LED and Speaker Header (SPK_PLED1)
20 USB 2.0 Header (USB_0_1)
21 Chassis/Water Pump Fan Connector (CHA_FAN4/WP)
22 RGB LED Header (RGB_LED1)
23 Addressable LED Header (ADDR_LED1)
24 5-pin underbolt AIC Connector (TB1)
25 Front Panel Audio Header (HD_AUDIO1)
26 Chassis/Water Pump Fan Connector (CHA_FAN2/WP)

ASROCK Z690M PG Riptide/D5 Specifications

General

Processor socket	LGA 1700
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR5-SDRAM
Maximum internal memory	128 GB
RAID levels	0, 1, 5, 10
Supported storage drive types	HDD & SSD
Number of storage drives supported	6
Supported storage drive interfaces	M.2, SATA III
Number of M.2 (M) slots	2
PCI Express x16 (Gen 5.x) slots	1
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
Parallel processing technology support	-
USB connector type	USB Type-A, USB Type-C
DisplayPort version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi	No
LAN controller	Killer E3100G
Ethernet interface type	2.5 Gigabit Ethernet
Audio chip	Realtek ALC897
Certification	- FCC, CE - ErP/EuP ready
Component for	PC
Motherboard chipset	Intel Z690
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 10 x64, Windows 11 x64
BIOS type	UEFI AMI
ACPI version	6.0
BIOS memory size	128 Mbit
System Management BIOS (SMBIOS) version	2.7
Harmonized System (HS) code	84733020
Weight	1000 g

Weight and Dimensions

Width	244 mm
Height	60 mm
