10
ASRock H61TM-ITX Motherboard
English
1.3 Pin Header Easy Installation Guide
ASRock motherboards are equipped with pin headers with obvious colors
that assist you to recognize the crucial headers. Please refer to the illustra-
tion of the onboard headers’ pin dention below. If you need more informa-
tion about the usage of these headers, please refer to “Onboard Headers
and Connectors” and “Jumper Setup” for details.
Front Panel
Audio Header
HDMI_SPDIF
Header
System Panel Header
USB 2.0 Header
USB 2.0 Header
Power LED Header
USB 3.0 Header
To Next Page
