ASRock H61TM-ITX Motherboard
7
English
Audio
7.1 CH HD Audio with Content Protection (Realtek ALC892
Audio Codec)
Premium Blu-ray audio support
LAN
PCIE x1 Gigabit LAN 10/100/1000 Mb/s
RTL8111E-VL
Supports Wake On LAN
Supports LAN Cable Detection
Supports Energy Efcient Ethernet 802.3az
Supports PXE
Rear Panel
I/O
1 x DC Jack
1 x DVI-I Port
1 x HDMI Port
1 x eSATA Connector
2 x USB 3.0 Ports by Etron EJ188
2 x USB 2.0 Ports
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
HD Audio Jacks: Front Speaker / Microphone
Connectors
2 x SATA2 3.0 Gb/s connectors, support NCQ, AHCI and
Hot Plug
1 x CIR header
1 x COM port header
1 x HDMI_SPDIF header
1 x LVDS connector
1 x LPC Debug header
1 x Home Theater PC header
1 x CPU Fan connector (4-pin)
1 x Chassis Fan connector (4-pin)
1 x Front Panel Audio connector
1 x Analog Surround Audio header
1 x Digital MIC header
1 x 3W Audio AMP Output Wafer header
1 x SATA Power connector
3 x USB 2.0 headers (support 5 USB 2.0 ports)
1 x USB 3.0 header by Etron EJ188 (supports 2 USB 3.0
ports)
BIOS
32Mb AMI UEFI Legal BIOS with GUI support
Supports “Plug and Play”
ACPI 1.1 Compliance Wake Up Events
Supports jumperfree
SMBIOS 2.3.1 Support
