Associated Electrics RC10 B74.2D TEAM KIT - Page 5

:: :: Bag 1Bag 1 - - Step Step 2 2
:: :: Bag Bag 11 - - Step 3 3
5
:: :: Bag 1 -Bag 1 - Step 1 Step 1
6/22
x7x725201
3x8mm
FHCS
x4x425201
M3x8mm
FHCS
25202
M3x10mm
FHCS
92315
B74 .2
Chassis
25215
M3
Locknut
x2x292112
Side Guards,
(left & right)
92113
Chassis
Brace,
Front
92113
Chassis
Brace,
Rear
Shorter battery O-ring strap
to be used with low-profi le
batteries. Longer battery
O-ring strap to be used with
standard height batteries.
92268 LP battery posts
included. These will not
be used in the kit and
can be discarded.
Multiple thickness spacers
included to tune battery
position which affects the
weight bias of the car.
Kit Setup uses the thinnest
spacer in front of the battery,
medium thickness spacer
behind the battery.
Position 3.
!
!
!
25211
M3x10mm
BHCS
92268
ESC
Tray
92268
Fan
Mount
92316
Battery
spacers
Fan
(Not included)
x2x2
x2x2
x2x2
31541
M3x6mm
FHCS
25202
M3x10mm
FHCS
31541
M3x6mm
FHCS
89203
M3x16mm
BHCS
92316
Battery
o-ring hook,
rear
92316
Battery
mount, rear
Shorter battery O-ring strap
to be used with low-profi le
!
x2x231519
M2.5x5mm
BHCS
92316
Battery
mount, front
92316
Battery
o-ring hook,
front
92316
Battery
o-ring
x2x24670
M3x8mm
SHSS
x4x431532
M3x8mm
BHCS
92255
Chassis brace
support, front
(G10 2mm)
92255
Chassis brace
support, rear
(G10 2mm)
